A loader is being used for construction work at the site.

Company profile

Shandong Feister Machinery Co., Ltd. specializes in the research, development, and manufacturing of high-end engineering equipment, with years of expertise in the loader sector. Its construction site loaders are specifically designed for complex working conditions such as building infrastructure projects, earthwork operations, and municipal construction.
Boasting concentrated power, high reliability, low fuel consumption, easy maintenance, and multi-functional integration, this equipment serves as the core solution for enhancing efficiency, reducing costs, and ensuring construction timelines across various construction sites.

Specialized loader for Construction Sites (Product Introduction)

Core Parameter Overview

Rated load capacity: 5000 kg
Total weight: 16,800 kg
Forklift bucket capacity: 2.7–4.5 m³
Engine power: 162 kW
Three items and time: 9.3s
System pressure: 17 MPa

Improve efficiency, reduce costs, and ensure project deadlines.

Product Parameters

Product Parameter
engine type	WD10G220E23	power rating	162kw
Engine Brand	Weichai	Number of cylinders	6
rated speed	2000r/min	Maximum traction force	170KN
Rated load capacity	5000kg	Chopper bucket width	3000mm
Volume Capacity	3m3	discharge height	3150mm
Maximum driving speed	40km/h	Hydraulic flow rate	224 L/min
Hydraulic oil tank capacity	150L	wheel base	3200mm
Fuel tank capacity	253L	displacement	9.726L
Tire Type	23.5-25	Overall dimensions of the machine	808529633463mm
scope of application	Engineering infrastructure construction, mining operations, port logistics, municipal sanitation services, agriculture, forestry, and livestock farming, industrial and mining enterprises

Workshop Details

Product Introduction and Features

Power System

Powered by the Weichai WP10WD10G220E23 engine, it delivers a rated power of 162 kW at 2000 rpm, offering high torque output even at low speeds with ample power reserve, ensuring robust performance for hill climbing, heavy-load loading, and continuous operations.

The matched optimization hydraulic transmission system combined with an efficient hydraulic system ensures seamless lifting, bucket retraction, and unloading operations, enabling rapid work cycles. This significantly enhances the efficiency of earthwork, sand and gravel, and building material handling at construction sites, allowing effortless management of high-intensity continuous construction tasks.
Hydraulic System: Dual-pump manifold + load-sensing system, with a system pressure of 17 MPa, ensuring smooth operation and coordinated compound actions.
Operation: Hydraulic pilot control with a lightweight handle and excellent precision positioning, featuring a floating three-position four-way valve for effortless high-precision operation; pilot oil is subjected to high-pressure filtration to prevent valve jamming.
Efficiency: The boom lifting time is 5.1 seconds, the three-phase lifting time is 9.3 seconds, the bucket capacity ranges from 2.7 to 4.5 m³, and the lifting force reaches 177 kN, ensuring high loading efficiency.

Durable Structure

Frame: The torsional stiffness of critical components increases by 20%; long wheelbase and large articulation ensure stable performance under heavy loads.
Working Assembly: Thickened high-strength steel plate + box-type welding, dual-level dust-proof joints + wear-resistant pins, offering impact resistance and long service life.
Counterweight and Tires: Increased rear counterweight results in higher overturn load capacity; standard equipment includes 23.5-25 engineering tires, with optional deep-pitch wear-resistant tires for harsh road conditions.

Cab: Comfortable, Safe, with Excellent

Space: A 360° panoramic cab with spacious, bright interior offering unobstructed visibility, featuring sliding windows for optimal ventilation.
Shock absorption: The shock absorption system ensures low indoor noise levels; the mechanical high-back suspended seat prevents fatigue during prolonged sitting.
Configuration: Standard features include air conditioning (heating and cooling), rearview camera/bell, and fire extinguisher, ensuring safer operations at construction sites.

Solid structure with durable resistance

The entire unit is constructed from high-strength, thickened steel plates, featuring a box-type frame with exceptional rigidity, impact resistance, and torsional stability without deformation.

Key components such as the boom, bucket, and pin shafts feature enhanced design; wear-prone parts are equipped with anti-wear protective plates, and the dust-proof sealing structure is robust. These features enable reliable performance in harsh construction environments-including mud, gravel, dust, and extreme temperatures-resulting in a low failure rate and extended service life during prolonged operation.

Flexible and versatile – one device for multiple uses

The articulated steering design features a small turning radius, enabling flexible movement through confined spaces such as narrow construction sites, around foundation pits, tunnels, and urban village redevelopment areas.

Standardized quick-change interfaces enable rapid attachment of various attachments-including standard buckets, enlarged buckets, wood grabbers, crushing hammers, sweepers, and snow plows. A single unit handles multiple site operations such as loading, transportation, demolition, cleaning, and material handling, significantly reducing equipment procurement and management costs.

Delivery, Payment, and Service

Transportation and Delivery

Equipped with a professional transportation team, the machinery and equipment are packaged in waterproof steel boxes to ensure their integrity during transit.

Payment Terms

Payment is only accepted via telegraphic transfer (T/T). Production will commence upon receipt of the 30% deposit, and the remaining 70% must be paid in full before shipment.

Service Provision

Real-time online after-sales support is provided through customized operation videos to promptly address usage inquiries.

Product certification

The certification covers CE, EAC, and ISO 9001 international management system certifications, demonstrating a firm commitment to rigorous standards and a strong sense of responsibility.
